[Advent of Code 2021] Day 8 | Seven Segment Search

Part 1

You barely reach the safety of the cave when the whale smashes into the cave mouth, collapsing it. Sensors indicate another exit to this cave at a much greater depth, so you have no choice but to press on.

As your submarine slowly makes its way through the cave system, you notice that the four-digit seven-segment displays in your submarine are malfunctioning; they must have been damaged during the escape. You'll be in a lot of trouble without them, so you'd better figure out what's wrong.

Each digit of a seven-segment display is rendered by turning on or off any of seven segments named a through g:

  0:      1:      2:      3:      4:
 aaaa    ....    aaaa    aaaa    ....
b    c  .    c  .    c  .    c  b    c
b    c  .    c  .    c  .    c  b    c
 ....    ....    dddd    dddd    dddd
e    f  .    f  e    .  .    f  .    f
e    f  .    f  e    .  .    f  .    f
 gggg    ....    gggg    gggg    ....

  5:      6:      7:      8:      9:
 aaaa    aaaa    aaaa    aaaa    aaaa
b    .  b    .  .    c  b    c  b    c
b    .  b    .  .    c  b    c  b    c
 dddd    dddd    ....    dddd    dddd
.    f  e    f  .    f  e    f  .    f
.    f  e    f  .    f  e    f  .    f
 gggg    gggg    ....    gggg    gggg

So, to render a 1, only segments c and f would be turned on; the rest would be off. To render a 7, only segments a, c, and f would be turned on.

The problem is that the signals which control the segments have been mixed up on each display. The submarine is still trying to display numbers by producing output on signal wires a through g, but those wires are connected to segments randomly. Worse, the wire/segment connections are mixed up separately for each four-digit display! (All of the digits within a display use the same connections, though.)

So, you might know that only signal wires b and g are turned on, but that doesn't mean segments b and g are turned on: the only digit that uses two segments is 1, so it must mean segments c and f are meant to be on. With just that information, you still can't tell which wire (b/g) goes to which segment (c/f). For that, you'll need to collect more information.

For each display, you watch the changing signals for a while, make a note of all ten unique signal patterns you see, and then write down a single four digit output value (your puzzle input). Using the signal patterns, you should be able to work out which pattern corresponds to which digit.

For example, here is what you might see in a single entry in your notes:

acedgfb cdfbe gcdfa fbcad dab cefabd cdfgeb eafb cagedb ab |
cdfeb fcadb cdfeb cdbaf

(The entry is wrapped here to two lines so it fits; in your notes, it will all be on a single line.)

Each entry consists of ten unique signal patterns, a | delimiter, and finally the four digit output value. Within an entry, the same wire/segment connections are used (but you don't know what the connections actually are). The unique signal patterns correspond to the ten different ways the submarine tries to render a digit using the current wire/segment connections. Because 7 is the only digit that uses three segments, dab in the above example means that to render a 7, signal lines d, a, and b are on. Because 4 is the only digit that uses four segments, eafb means that to render a 4, signal lines e, a, f, and b are on.

Using this information, you should be able to work out which combination of signal wires corresponds to each of the ten digits. Then, you can decode the four digit output value. Unfortunately, in the above example, all of the digits in the output value (cdfeb fcadb cdfeb cdbaf) use five segments and are more difficult to deduce.

For now, focus on the easy digits. Consider this larger example:

be cfbegad cbdgef fgaecd cgeb fdcge agebfd fecdb fabcd edb |
fdgacbe cefdb cefbgd gcbe
edbfga begcd cbg gc gcadebf fbgde acbgfd abcde gfcbed gfec |
fcgedb cgb dgebacf gc
fgaebd cg bdaec gdafb agbcfd gdcbef bgcad gfac gcb cdgabef |
cg cg fdcagb cbg
fbegcd cbd adcefb dageb afcb bc aefdc ecdab fgdeca fcdbega |
efabcd cedba gadfec cb
aecbfdg fbg gf bafeg dbefa fcge gcbea fcaegb dgceab fcbdga |
gecf egdcabf bgf bfgea
fgeab ca afcebg bdacfeg cfaedg gcfdb baec bfadeg bafgc acf |
gebdcfa ecba ca fadegcb
dbcfg fgd bdegcaf fgec aegbdf ecdfab fbedc dacgb gdcebf gf |
cefg dcbef fcge gbcadfe
bdfegc cbegaf gecbf dfcage bdacg ed bedf ced adcbefg gebcd |
ed bcgafe cdgba cbgef
egadfb cdbfeg cegd fecab cgb gbdefca cg fgcdab egfdb bfceg |
gbdfcae bgc cg cgb
gcafb gcf dcaebfg ecagb gf abcdeg gaef cafbge fdbac fegbdc |
fgae cfgab fg bagce

Because the digits 1, 4, 7, and 8 each use a unique number of segments, you should be able to tell which combinations of signals correspond to those digits. Counting only digits in the output values (the part after | on each line), in the above example, there are _26_ instances of digits that use a unique number of segments (highlighted above).

In the output values, how many times do digits 1, 4, 7, or 8 appear?

Proposed solution: iterate over the output values and count the number of times the digits 1, 4, 7, and 8 appears

Time complexity: O(n)

Space complexity: O(1)

#!/usr/bin/env python3
import sys

if len(sys.argv) != 2:
    print("Usage: {} <input file>".format(sys.argv[0]))
    sys.exit(1)

file_input = open(sys.argv[1], "r").read().strip().split("\n")

simple_digits = 0
for line in file_input:
    output = line.split("|")[1].split()
    for code in output:
        if len(code) in [2,4,3,7]:
            simple_digits += 1

print("Simple digits: " + str(simple_digits))

1 has two segments lit, 4 has four segments lit, 7 has three segments lit and 8 has all seven segment lit. These are all unique in that way since no other numbers map to those unique number of segments. This is also why we are counting them.

  1:         4:         7:         8:
 ....       ....       aaaa       aaaa
.    c     b    c     .    c     b    c
.    c     b    c     .    c     b    c
 ....       dddd       ....       dddd
.    f     .    f     .    f     e    f
.    f     .    f     .    f     e    f
 ....       ....       ....       gggg

❯ python3 solution8.py input8
Simple digits: 416

Part 2

Through a little deduction, you should now be able to determine the remaining digits. Consider again the first example above:

acedgfb cdfbe gcdfa fbcad dab cefabd cdfgeb eafb cagedb ab |
cdfeb fcadb cdfeb cdbaf

After some careful analysis, the mapping between signal wires and segments only make sense in the following configuration:

 dddd
e    a
e    a
 ffff
g    b
g    b
 cccc

So, the unique signal patterns would correspond to the following digits:

• acedgfb: 8
• cdfbe: 5
• gcdfa: 2
• fbcad: 3
• dab: 7
• cefabd: 9
• cdfgeb: 6
• eafb: 4
• cagedb: 0
• ab: 1

Then, the four digits of the output value can be decoded:

• cdfeb: _5_
• fcadb: _3_
• cdfeb: _5_
• cdbaf: _3_

Therefore, the output value for this entry is _5353_.

Following this same process for each entry in the second, larger example above, the output value of each entry can be determined:

• fdgacbe cefdb cefbgd gcbe: 8394
• fcgedb cgb dgebacf gc: 9781
• cg cg fdcagb cbg: 1197
• efabcd cedba gadfec cb: 9361
• gecf egdcabf bgf bfgea: 4873
• gebdcfa ecba ca fadegcb: 8418
• cefg dcbef fcge gbcadfe: 4548
• ed bcgafe cdgba cbgef: 1625
• gbdfcae bgc cg cgb: 8717
• fgae cfgab fg bagce: 4315

Adding all of the output values in this larger example produces _61229_.

For each entry, determine all of the wire/segment connections and decode the four-digit output values. What do you get if you add up all of the output values?

Proposed solution: iterate through the input values and use sets and set operations to determine the wiring configuration per line – use the configuration to decode the output values and take their sum

Time complexity: O(n)

Space complexity: O(1)

I am going define the sets like the following:

set(1) = len(2)
set(7) = len(3)
set(4) = len(4)
set(8) = len(7)

Here I am saying that the segments for 1 by definition has an input length of two. Same idea for the segment sets for the numbers 7, 4, and 8 as well. These are the numbers from part 1 which we can easily identify just from the input length.

len(6) = set(9) | set(6) | set(0)
len(5) = set(3) | set(2) | set(5)

Above, I am specifying the possible sets for a given wiring configuration length. We know that the sets for 9, 6, and 0 all must have a length of 6 because they have 6 segments and the sets for 3, 2, and 5 all have a length of 5.

  0:         6:         9:
 aaaa       aaaa       aaaa
b    c     b    .     b    c
b    c     b    .     b    c
 ....       dddd       dddd
e    f     e    f     .    f
e    f     e    f     .    f
 gggg       gggg       gggg

  5:         2:         3:
 aaaa       aaaa       aaaa
b    .     .    c     .    c
b    .     .    c     .    c
 dddd       dddd       dddd
.    f     e    .     .    f
.    f     e    .     .    f
 gggg       gggg       gggg

From here, I can identify the next set and also the wire configuration for the top segment.

top    = set(7) - set(1)
set(9) = len(6) & issubset(set(4))

The top segment is the set difference between set 7 and set 1. Since the segments for 7 include all of the segments for 1 and the top segment, we can use this set difference to get this top label. Set 9 is the only number that has the segments for 4 as a subset. We can search for this in the three wire configurations with a length of 6.

bottom = set(9) - set(4) - top
set(0) = len(6) & not(set(9)) & issubset(set(1))
set(6) = len(6) & not(set(9)) & not(set(0))
set(3) = len(5) & issubset(set(1))
set(5) = len(5) & not(set(3)) & set(5) + set(9) == set(9)
set(2) = len(5) & not(set(3)) & not(set(5))

The bottom wire has to be set 9 minus set 4 minus the top wire, although this does not prove too useful for the remainder of the sets. Set 0 can be narrowed down with the following rules:

1. 0 has six segments
2. Has the segments of set 1 as a subset
3. Is not set 9

The only possible configuration after these filters is the wiring for set 0. For set 6, we know that it is not set 9 or set 0 (which we have narrowed down already) and so it must be the single remaining configuration with a length of 6.

Only the wiring for numbers with segment lengths of 5 are left. Set 3 is the only one from this group with set 1 as a subset. Set 5 can be narrowed down with the following rules:

1. 5 has five segments
2. When the set is added to set 9, the resulting set should equal set 9 (another way of saying set 5 is a subset of set 9)
3. Is not set 3

Finally, set 2 is the remaining set with length 5, and the remaining set in general. The code makes more sense after this:

#!/usr/bin/env python3
import sys

if len(sys.argv) != 2:
    print("Usage: {} <input file>".format(sys.argv[0]))
    sys.exit(1)

file_input = open(sys.argv[1], "r").read().strip().split("\n")

# set(1) = len(2)
# set(7) = len(3)
# set(4) = len(4)
# set(8) = len(7)
# len(6) = set(9) | set(6) | set(0)
# len(5) = set(3) | set(2) | set(5)
# top    = set(7) - set(1)
# set(9) = len(6) & issubset(set(4))
# bottom = set(9) - set(4) - top
# set(0) = len(6) & not(set(9)) & issubset(set(1))
# set(6) = len(6) & not(set(9)) & not(set(0))
# set(3) = len(5) & issubset(set(1))
# set(5) = len(5) & not(set(3)) & set(5) + set(9) == set(9)
# set(2) = len(5) & not(set(3)) & not(set(5))

total = 0
for line in file_input:
    length_map = {i:[] for i in range(2,8)}
    inp, output = [x.split() for x in line.split("|")]
    for i in inp:
        length_map[len(i)].append(i)
    set1 = set(length_map[2][0])
    set7 = set(length_map[3][0])
    set4 = set(length_map[4][0])
    set8 = set(length_map[7][0])
    len5 = [set(x) for x in length_map[5]]
    len6 = [set(x) for x in length_map[6]]
    top = set7 - set1
    set9 = list(filter(lambda x: set4.issubset(x), len6))[0]
    bottom = set9 - set4 - top
    set0 = list(filter(lambda x: x != set9 and set1.issubset(x), len6))[0]
    set6 = list(filter(lambda x: x != set0 and x != set9, len6))[0]
    set3 = list(filter(lambda x: set1.issubset(x), len5))[0]
    set5 = list(filter(lambda x: x != set3 and x.union(set9) == set9, len5))[0]
    set2 = list(filter(lambda x: x != set3 and x != set5, len5))[0]
    configurations = {
        frozenset(set0): 0,
        frozenset(set1): 1,
        frozenset(set2): 2,
        frozenset(set3): 3,
        frozenset(set4): 4,
        frozenset(set5): 5,
        frozenset(set6): 6,
        frozenset(set7): 7,
        frozenset(set8): 8,
        frozenset(set9): 9
    }
    result = ""
    for num in output:
        result += str(configurations[frozenset(num)])
    result = int(result)
    total += result

print("Final total: " + str(total))

❯ python3 solution8.py input8
Final total: 1043697
